6. Click and drag any of the bounding-box handles until the shape’s height
and width matches the template art.
Click and drag any of the
bounding-box handles to
resize the Live Shape. Dragging the bounding-
box handles changes the
The Rectangle
tool is still active. shape’s size properties.

7. In the Transform panel, make sure the link between the Corner Radius Note:
fi elds is active, then change any of the fi elds to 0.05 in.
To show corner widgets,
Remember, you hid the Corner Widgets in an earlier exercise. If they were visible, you choose View>Show
could drag the live widgets to change the shape’s corner radius.
Corner Widgets.

The Rectangle Use these fields to
tool is still active. change the corner
radius if the on-screen
widgets are not visible.
8. With the object selected, click the Swap Fill and Stroke button at the
bottom of the Tools panel.

Swap Fill and
Stroke button

9. Choose the Ellipse tool (nested under the Rectangle tool).

10. Press Option/Alt, then click at the center of the fi gure’s head and drag out.
Use the Smart Guides to create a shape with equal height and width.
Pressing Option/Alt while you draw creates the new shape with its center at the point
where you click. You can press Shift to constrain the new shape to a circle, or simply
use the Smart Guides.

Again, ellipses are recognized by Illustrator’s Live Shapes functionality. Th e Transform
panel shows options that are relative to an ellipse.

Option/Alt-click the
center of the figure’s
head to draw out
from the center.

Ellipse tool

11. If necessary, adjust the circle’s size and position until you are satisfi ed with
the results.

12. Save the fi le and continue to the next exercise.

Project 1: Campground Icons 81
