5. Click the Layers tab to display those options.
PDF and native Illustrator files can include multiple layers. You
can determine which layers to display in the placed file by toggling
the eye icons on or off in the Show Layers list. In the Update Link
Options menu, you can determine what happens when/if you update
the link to the placed file.
• Keep Layer Visibility Overrides maintains your choices
regarding which layers are visible in the InDesign layout.
• Use PDF’s Layer Visibility restores the layer status as saved in
the placed file.

6. Click OK to load the cursor with the placed file.
By default, the loaded Place cursor shows a small thumbnail of the
file you’re placing. You can turn off the thumbnail preview feature by
unchecking the Show Thumbnails on Place option in the Interface pane
of the Preferences dialog box.

7. Click near the top-left corner of the page to place the image.
Every image in an InDesign layout exists in a frame. When you click an empty area of
the page to place an image, the containing frame is automatically created for you.
Note:
In the layout, blue handles and frame edges indicate that the frame is selected on the If you press Shift when
page, not the content inside the frame; values in the Control panel relate to the actual
containing frame. clicking Open in the
Place dialog box, the
8. Using the Control panel, choose the top-left reference point and then Place [Format] dialog
change the frame’s position to X: 0.25 in, Y: 0.25 in. box for the selected file
appears even if Show
Position the object’s Import Options is not
top-left corner at checked.
X: 0.25 in, Y: 0.25”.

The blue handles
show the edge of the
graphics frame that
contains the logo.

56 Project 1: Letterhead Design
