4. Choose Select>Deselect to turn off the current selection.
Although you could keep adding to the selection with the Magic Wand tool, the
marching ants can’t really show the fine detail.

5. Choose Select>Color Range.

6. Make sure the Localized Color Clusters option is unchecked.

7. Choose White Matte in the Selection Preview menu (if it is not already).
Note:
By changing the Selection Preview, you can more easily determine exactly what is
selected. You can preview color range selections in the image window as: Because the dialog box
• None shows the normal image in the document window. preview is so small,
we prefer to rely on
• Grayscale shows the entire image in shades of gray; selected areas are solid white
and unselected areas are solid black. the preview in the
document window,
• Black Matte shows unselected areas in solid black; selected areas appear in color.
which is controlled in the
• White Matte shows unselected areas in solid white; selected areas appear in color. Selection Preview menu
• Quick Mask adds a partially transparent overlay to unselected areas. at the bottom of the
dialog box.
8. Set the Fuzziness value to 25 and click anywhere in the blue sky (in the
document window).
Fuzziness is similar to the Tolerance setting for the Magic Wand tool. Higher Fuzziness
values allow you to select more variation from the color you click.
Depending on where you clicked, your selection might not exactly match what you
see in our screen shot. For now, the important point is to know that the visible areas
indicate the current selection.

Click in the Eyedropper tool
image to select
a blue value. Add to Sample
Subtract from Sample
Lighter blue indicates
areas that aren’t
entirely selected.
The low Fuzziness
value doesn’t select
The White Matte a large enough
preview shows range of blues.
unselected areas
in white.

68 Project 1: Composite Movie Ad
