7. In the Frame Fitting Options dialog box, activate the Auto-Fit option.
Choose Fill Frame Proportionally in the Fitting menu, choose the center
point in the Align From proxy, and click OK.
When an image is placed into this frame, it will fill the
entire frame and the aspect ratio of the image will be
maintained. The Align From reference points determine
the position of the placed content relative to the frame.

8. With the Selection tool still active, click the seventh frame to select it.
When you are already “inside” a group, you can use the Selection tool to select another
individual object within the same group.

9. Click the Auto-Fit option in the Control panel.
Because the center registration point is the default Content Fitting option, you do not Note:
need to open the Frame Fitting Options dialog box for each frame in this filmstrip.
You can also use the
Direct Selection tool to
10. Repeat Steps 8–9 for the remaining six placeholder frames.
select individual objects
11. Choose File>Place. If necessary, navigate to the WIP>Letterhead folder. within a group.
Uncheck all options at the bottom of the dialog box.
If you leave Show Import Options checked, you would see the TIFF Options dialog box
for each of the selected images. In this case you simply want to place the images, so you
don’t need to review the file options.

12. Click thumb1.tif to select it. Press Shift and click thumb8.tif to select it
and all in-between files.
In many cases, you will need to place more than one image from the same location into
an InDesign layout. You can streamline the process by loading multiple images into the
cursor at once and then clicking to place each image in the correct location.

Note:
Press Shift to select
multiple contiguous files
in a dialog box.

Press Command/Control
to select multiple
non-contiguous files.

64 Project 1: Letterhead Design
