Page 45 - CC2017_PS_Look_Inside

4. Click in the image window and drag until the Tantamount layer content
snaps to the bottom-right live-area guides.

If you toggled off the Snap feature when you used the Crop tool, you should turn it
back on now by choosing View>Snap.

Uncheck
this option.
Move tool
Select the layer you
want to move, then
click and drag in the
document window to
move the layer content.

5. Click the Rating layer in the Layers panel to select that layer.

6. Click in the image window and drag until the Rating layer content snaps to
the bottom-left live-area guides.
Note:
7. With the Rating layer still active, choose Edit>Free Transform.
You can also use the
When you use the transform options, bounding box handles surround the selection in Edit>Transform
the document window. The Options bar gives you a number of options for controlling submenu to apply specific
the transformations numerically:
transformations to a layer
A. Reference Point Location. This point determines the point around which or selection.
transformations are made. It always defaults to the center point.
B. Set Horizontal Position of Reference Point. This is A B C D E F G H I J K
the X position of the reference point for the content
being transformed. If the center reference point is
selected, for example, this is the X position of the
center point of the active content.
C. Use Relative Positioning for Reference Point. If this
option is active, the Set Horizontal Position and Set
Vertical Position fields default to 0; changing these values
moves the reference point by the value you type. For
example, typing “–25” in the Set Horizontal Posi tion field
moves the active content 25 pixels to the left.
D. Set Vertical Position of Reference Point. This is the
Y position of the reference point for the content being Bounding box handles
transformed. surround the content that
E. Set Horizontal Scale. Use this field to change the is being transformed.
horizontal scale percentage of the transformed content.
F. Maintain Aspect Ratio. When active, the horizontal scale and vertical scale fields
are locked to have the same value.
G. Set Vertical Scale. Use this field to change the vertical scale percentage of the
transformed content.
H. Rotate. Use this field to rotate the transformed content by a specific angle.
I. Switch Between Free Transform and Warp Modes. If available, click this button
to apply a built-in warp to the active selection.
J. Cancel Transform. Click this button (or press the Esc key) to exit Free Transform
mode without applying any transformation.
K. Commit Transform. Click this button (or press Return/Enter) to finalize the
transformation that you applied while in Free Transform mode.

Project 1: Composite Movie Ad 55
