5. Zoom out until you can see the entire canvas in the document window.
Note:
6. Click inside the crop area and drag to reposition the image so that it is You can also use the
approximately centered in the crop area. Arrow keys on your
When you change the size of the marquee, the area outside the marquee is “shielded” by keyboard to “nudge”
a darkened overlay so you can get an idea of what will remain after you finalize the crop. the image in a specific
direction.
You can drag the image inside the crop area to change the portion that will remain in
the cropped image. By default, the crop area remains centered in the document window;
instead, the image moves behind the crop area.

Click and drag inside
the crop area to change
the portion of the
image inside the crop.

Note:
It might be helpful
Areas outside the to toggle off the Snap
crop marquee are feature (View>Snap),
partially obscured.
which causes certain
file elements to act as
magnets when you move
7. Press Return/Enter to finalize the crop. a marquee or drag a
selection.
8. Choose View>New Guide Layout.
This dialog box makes it very easy to define a page grid using non-printing guides. The Note:
dialog box defaults to add 8 columns with a 20-pixel (0.067 in) gutter. In the document
window, you can see the guides (blue lines) that will be created based on the active Remember: panels can
settings in the New Guide Layout dialog box. always be accessed in the
Window menu.

Note:
If rulers are not visble,
choose View>Rulers
or press Command/
Control-R.

Note:
The X coordinate refers
to an object’s horizontal
position and Y refers to
the vertical position.

Project 1: Composite Movie Ad 33
