Image Resolution
When a printer creates halftone dots, it calculates
the average value of a group of pixels in the raster
image and generates a spot of appropriate size. A
raster image’s resolution — measured in pixels
per inch (ppi) — determines the quantity of
pixel data the printer can read. Regardless of their
source — camera, scanner, or files created in
Photoshop — images need to have sufficient
resolution so the output device can generate
enough halftone dots to create the appearance of
continuous tone. In the images above, the same raster image is reproduced at 300 ppi (left) and
72 ppi (right); notice the obvious degradation in quality in the 72-ppi version.
Ideally, the printer will have four pixels for each halftone dot created. In the image to the
right, each white square represents a pixel. The highlighted
area shows the pixel information used to generate a halftone
dot. If an image only has 72 pixels per inch, the output device
has to generate four halftone dots per pixel, resulting in poor
printed quality.
The relationship between pixels and halftone dots defines
the rule of resolution for raster-based images — the resolution
of a raster image (ppi) should be two times the screen ruling
(lpi) that will be used for printing.
For line art, the general rule is to scan the image at the
same resolution as the output device. Many laser printers and digital presses image at 600–1200
dots per inch (dpi); imagesetters used to make printing plates for a commercial press typically
output at much higher resolution, possibly 2400 dpi or more.

oPen And resize An imAge
Every raster image has a defined, specific resolution that is established when the image
is created. If you scan an image to be 33 high by 33 wide at 150 ppi, that image has
450 pixels in each vertical column and 450 pixels in each horizontal row. Simply
resizing the image stretches or compresses those pixels into a different physical space,
but does not add or remove pixel information. If you resize the 3 × 33 image to
6 × 63 (200% of the original), the 450 pixels in each column or row are forced to
extend across 63 instead of 33, causing a marked loss of quality.
The effective resolution of an image is the resolution calculated after any scaling
is taken into account. This number is equally important as the original image
resolution — and perhaps more so. The effective resolution can be calculated with a
fairly simple equation:
Original resolution ÷ (% magnification ÷ 100) = Effective resolution

If a 300-ppi image is magnified 150%, the effective resolution is:
300 ppi ÷ 1.5 = 200 ppi

In other words, the more you enlarge a raster image, the lower its effective
resolution becomes. In general, you can make an image 10% or 15% larger without
significant adverse effects; the more you enlarge an image, however, the worse the
results. Even Photoshop, which offers very sophisticated formulas (called “algorithms”)
for sizing images, cannot guarantee perfect results.
